- General Information
- Manufacturer
- Advantech Co., Ltd
- Manufacturer Website Address
- http://www.advantech.com
- Brand Name
- Advantech
- Product Series
- ADAM-6521
- Product Type
- Ethernet Switch
- Warranty
- Limited Warranty
- 2 Year
- Technical Information
- Features
- IP30
- Broadcast Storm Control
- Interfaces/Ports
- Total Number of Network Ports
- 4
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 4 x 10/100 BASE-T Ethernet RJ-45 Network Port
- 1 x 100 Ethernet Multi-Mode SC Connector
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Fiber Mode Supported
- Multi-mode
- Ethernet Technology
- Fast Ethernet
- Network Technology
- 10/100Base-T
- 100Base-X
- Maximum Data Transfer Rate
- 12.50 MB/s
- Network & Communication
- Layer Supported
- 2
- Management & Protocols
- Manageable
- No
- Power Description
- PoE (RJ-45) Port
- No
- Input Voltage
- 10 V DC
- 30 V DC
- Power Source
- DC
- Power Consumption
- 3 W
- Plug/Connector Type
- Terminal Block
- Physical Characteristics
- Product Material
- Plastic
- Form Factor
- DIN Rail Mountable
- Wall Mountable
- Enclosure
- Height
- 4.4"
- Width
- 2.8"
- Depth
- 1.1"
- Miscellaneous
- Application/Usage
- Network
