- General Information
- Manufacturer
- Cisco Systems, Inc
- Manufacturer Website Address
- http://www.cisco.com
- Brand Name
- Cisco
- Product Line
- Catalyst
- Product Series
- IW9167
- Product Condition
- Refurbished
- Product Type
- Wireless Access Point
- Warranty
- Limited Warranty
- 1 Year
- Technical Information
- Wireless LAN Standard
- IEEE 802.11a/b/g/n/ac/ax/d/h/i/r/k/v/u
- Bluetooth Standard
- Bluetooth 5
- Network Band
- Tri Band
- Frequency Band
- 2.40 GHz
- 5 GHz
- 6 GHz
- Indoor/Outdoor
- Outdoor
- Wireless Transmission Speed
- 7.80 Gbit/s
- MIMO Technology
- Yes
- Beamforming Technology
- Yes
- Data Encryption
- Yes
- Encryption Standard
- WPA3
- WPA2
- WPA
- AES
- TKIP
- EAP-TLS
- EAP-TTLS
- EAP-FAST
- PEAPv1
- EAP-GTC
- EAP-SIM
- Ingress Protection (IP) Rating
- IP67
- Interfaces/Ports
- Ethernet Technology
- 5 Gigabit Ethernet
- 10 Gigabit Ethernet
- Number of Network (RJ-45) Ports
- 2
- PoE PD Port
- Yes
- Management Port
- Yes
- Network & Communication
- Wi-Fi Generation
- Wi-Fi 6E
- Physical Characteristics
- Antenna Form Factor
- External
- Height
- 2.8"
- Width
- 11.5"
- Depth
- 10.5"
- Weight (Approximate)
- 9.20 lb
- Miscellaneous
- Certifications & Standards
- EN 60529 IP67
- UL50E Type 4X
- IEC 60068-2-1 (Cold)
- IEC 60068-2-2 (Dry Heat)
- IEC 60068-2-14 (Change of Temperature)
- IEC 60068-2-30 (Damp Heat)
- IEC 60068-2-6 (Vibration)
- IEC 60068-2-27 (Shock)
- IEC 60068-2-30 (Humidity)
- IEC 60068-2-32 (Freefall)
- IEC 60068-3-3 (Seismic)
- FCC 47 CFR Part 15 Class A
- EN 55032 Class A
- VCCI Class A
- AS/NZ CISPR 32 Class A
- CISPR 32 Class A
- ICES 003 Class A
- CNS13438 Class A
- EN 300 386
- KS C 9832:2019
- EN 301 489-1 v2.1.1
- EN 301 489-17 v2.1.1
- EN 301 489 - 19
- EN 55035
- CISPR35
- KS C 9835:2019
- KS X 3124
- KS X 3126
- IEC/EN 61000-4-2 - Electrostatic Discharge
- IEC/EN 61000-4-3 - Radiated RF Immunity
- IEC/EN 61000-4-5 - Surge
- IEC/EN 61000-4-6 - Conducted RF Immunity
- IEC/EN 61000-4-8 - Power Frequency
- Magnetic Field
- IEC 61000-4-9 - Pulsed Magnetic Field
- IEC 61000-4-11 - AC Voltage Dips
- IEC 61000-4-18 - Damped Oscillatory Wave
- EN-61000-4-29 - DC Voltage Dips
- IEC 62368-1
- EN 62368-1
- EN 62311
- EN 45545-3
- DIN 5510-2
- EN 61000-6-2 - Industrial
- EN 61000-6-4 - Industrial
- EN 61000-6-1 - Light Industrial
- AREMA C&S Manual Section 11.5.1
- AAR S9401 Rail - Rolling stock cab, wayside outside
- EN 50155 Rail - Electronic Equipment on Rolling Stock Class TX (EMC, Environmental)
- EN 61373 Rail - Environmental
- EN 50121-4 Rail - Signaling and Telecommunications Apparatus
- EN 50121-3-2 Rail - Apparatus for Rolling Stock
- EN 61373 - Shock and Vibration
- ? FCC Part 15.247, 15.407
- ? RSS 247
- ? EN 300 328 v2.2.2 (EU)
- ? EN 301 893 v2.1.1 (EU)
- ? EN 303 413
- ? ARIB-STD 66 (Japan)
- ? ARIB-STD T71 (Japan)
- ? EMI and susceptibility (Class B)
- Environmentally Friendly
- Yes
- Environmental Compliance
- Waste Electrical and Electronic Equipment Directive (WEEE)
