- General Information
- Manufacturer
- Eaton Corporation
- Manufacturer Website Address
- http://www.eaton.com
- Brand Name
- Eaton
- Product Series
- 9PX
- Product Type
- Double Conversion Online UPS
- Warranty
- Limited Warranty
- 3 Year
- Technical Information
- Plug/Connector Type
- NEMA 5-15P
- Receptacle Type
- NEMA 5-15R
- Receptacle Detail
- 8 x NEMA 5-15R
- Application/Usage
- IT
- Features
- Advanced Battery Management (ABM)
- Built-in Bypass Switch
- Power Description
- Load Capacity (VA)
- 1000 VA
- Load Capacity (Watt)
- 900 W
- Input Voltage
- 120 V AC
- Output Voltage
- 120 V AC
- 100 V AC
- 110 V AC
- 125 V AC
- Input Frequency
- 40 Hz
- 50 Hz
- 60 Hz
- 70 Hz
- Output Frequency
- 50 Hz
- 60 Hz
- Output Power Factor
- 0.9
- Management
- Network Management
- RS-232
- SNMP/Web
- Network-M3 Card
- INDGW-M2 Card
- Relay-MS Card
- Interfaces/Ports
- Serial Port
- Yes
- USB
- Yes
- EPO Port
- Yes
- Number of USB Ports
- 1
- Expansion Slot Detail
- 1 x Mini-Slot (MS) expansion port
- Battery Information
- Battery Characteristics
- Sealed
- Battery Chemistry
- Lead Acid
- Hot Swappable
- Yes
- Physical Characteristics
- Color Family
- Dual Color
- Product Color
- Black
- Silver
- Height
- 3.4"
- Width
- 17.3"
- Depth
- 17.7"
- Rack Height
- 2U
- Form Factor
- Rack/Tower
- Weight (Approximate)
- 36.40 lb
- Miscellaneous
- Package Contents
- 9PX1000RT 1000VA Rack/Tower UPS
- 4-post Rail Kit
- Safety Manual
- User Manual
- Tower Pedestals
- RS-232 Serial Cable
- USB Cable
- Intelligent Power Software Suite CD
- Network-M3 Network card
- EMPDT1H1C2 EMP
- EMSU052XXX-6009UC Startup
- EMWFLN75XX- 2509UC 5 year onsite, next day response
- EMXX5YNEXX-6009UC 5 year PredictPulse
- Certifications & Standards
- IEC 62040-2 Cat C1
- CISPR22 Class B
- FCC part 15 Class B
- VCCI Class B
- cULus Listed
- NOM
