- General Information
- Manufacturer
- HP Inc.
- Manufacturer Website Address
- http://www.hp.com
- Brand Name
- HP
- Product Series
- Z2 G9
- Product Type
- Workstation
Overview | Full size Z tower power at half the size
Get all the power of a full size tower at a fraction of the size. Reengineered to fit full-height, full-length graphics while leaving room for upgrades and expansion, the Z2 SFF delivers high performance for your intensive workflow-from 3D design to real time ray tracing-now and in the future.
Full height, full length performance
Design, simulate and real time ray trace on a Z SFF -- FHFL pro graphics and Intel® Core™ processors.
ISV Certified
Work with confidence knowing your PC is certified with leading software applications to ensure peak performance.
Configurable for today. Expandable for tomorrow.
Accelerate your current workflow with options across processor, graphics, memory, storage, and I/O ports.
Features | Windows 11
Work anywhere without compromising on performance or security with Windows 11 powered by HP's collaboration and connectivity technology.
Intel® Core™ i7 processor
Run several CPU-heavy programs simultaneously without sacrificing performance with an Intel® Core™ i7 processor.
Security is your top priority
The HP Wolf Pro Security Edition provides preconfigured enterprise-level PC protection for small and medium sized businesses.
AMD Radeon™ Pro WX 3200 graphics card
Get reliable performance on today's most popular design, manufacturing and AEC apps with AMD Radeon™ Pro WX 3200 graphics. Easily handle workflows using small to medium assemblies with simple parts.
Smaller, Functional Design
The stunning new design features front and rear ledges, so you can easily move your system from location to location.
- Processor
- Number of Processors Supported
- 1
- Number of Processors Installed
- 1
- Processor Type
- Core i7
- Processor Generation
- 12th Gen
- Processor Model
- i7-12700
- Processor Core
- Dodeca-core (12 Core)
- Processor Speed
- 2.10 GHz
- vPro Technology
- Yes
- Processor Socket
- Socket LGA-1700
- Chipset
- Chipset Manufacturer
- Intel
- Chipset Model
- W680
- Memory
- Standard Memory
- 16 GB
- Maximum Memory Supported
- 128 GB
- Memory Technology
- DDR5 SDRAM
- Total Number of Memory Slots
- 4
- Error Checking
- Non-ECC
- Intel Optane Memory Ready
- No
- Memory Clock Speed
- 4.80 GHz
- Memory Configuration
- 1 x 16GB
- Signal Processing
- Unbuffered
- Storage
- Total Solid State Drive Capacity
- 512 GB
- Solid State Drive Interface
- PCI Express NVMe 4.0 x4
- Controllers
- Controller Type
- Serial ATA/600
- RAID Supported
- Yes
- RAID Levels
- 0, 1
- Display & Graphics
- Graphics Controller Model
- Radeon Pro WX 3200
- Graphics Memory Capacity
- 4 GB
- Graphics Memory Accessibility
- Dedicated
- Network & Communication
- Ethernet Technology
- Gigabit Ethernet
- Interfaces/Ports
- Total Number of USB Ports
- 11
- USB Type-C
- Yes
- USB Type-C Detail
- 1 SuperSpeed USB Type-C® 20Gbps signaling rate (USB Power Delivery, DisplayPort™ 1.4, HP Sleep and Charge)
- DisplayPort
- Yes
- Number Of Ethernet Ports
- 1
- Number of DisplayPort Outputs
- 2
- Operating System
- Operating System Platform
- Windows
- Operating System
- Windows 11 Pro
- Downgradable Operating System
- Windows 10 Pro
- Power Description
- Input Voltage
- 120 V AC
- 230 V AC
- Maximum Power Supply Wattage
- 450 W
- Frequency
- 50 Hz
- 60 Hz
- Physical Characteristics
- Color Family
- Black
- Product Color
- Black
- Form Factor
- Small Form Factor
- Height
- 3.9"
- Width
- 15.1"
- Depth
- 12.1"
- Weight (Approximate)
- 11.02 lb
- Miscellaneous
- Package Contents
- Z2 Small Form Factor G9 Workstation
- Keyboard
- Mouse
- Energy Star
- Yes
- Environmentally Friendly
- Yes
- Environmental Certification
- Electronic Product Environmental Assessment Tool Gold (EPEAT Gold)
- Energy Efficiency Certification
- China Energy Conservation Program (CECP)
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
- Waste Electrical and Electronic Equipment Directive (WEEE)
