3 LAN Ports Meet Minimal Deployment Effort
InSight S345-4G offers industry-first three LAN ports, enabling simultaneous connectivity for up to three devices as you need. It is ideal for coupling with solar power systems to eliminate additional wiring deployments.
Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.
LightPro Night Vision Technology
The VIGI LightPro Night Vision Technology intelligently switches between IR night vision and full-color night vision by detecting people or vehicles. This allows the camera to capture clearer and more critical details with the white light on, and to reduce light pollution and energy consumption with the IR light on at most time, effectively adapting to a broader range of scenarios.
Smart Video Enhancement Technology
True WDR:By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.
Smart IR:Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.
3D DNR:3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.
White Balance:White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.
- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com/us
- Brand Name
- VIGI
- Product Line
- InSight
- Product Type
- Network Camera
- Technical Information
- HD Recording
- Yes
- Night Vision
- Yes
- Night Vision Distance
- 164.04 ft
- Night Vision Type
- Infrared/Color
- Number of IR LEDs
- 2
- AI-powered
- Yes
- Infrared (IR) Cut-off Filter
- Yes
- Wide Dynamic Range Detail
- 120 dB
- Display & Graphics
- Image Sensor Type
- CMOS
- Image Sensor Size
- 1/2.9"
- Color Supported
- Color
- Field of View
- Horizontal FOV: 86°, Vertical FOV: 43°, Diagonal FOV: 95°
- Effective Camera Resolution
- 4 Megapixel
- Video
- Video Formats
- H.265+
- H.265
- H.264
- H.264+
- H.264H
- H.265M
- Maximum Video Resolution
- 2688 x 1520
- Maximum Frame Rate
- 30 fps
- Audio
- Audio Support
- Yes
- Lens
- Lens Type
- Fixed
- Maximum Focal Length
- 4 mm
- Lens Included
- Yes
- Lens Mount Type
- M12-mount
- Maximum Aperture
- f/1.6
- Exposure
- Shortest Shutter Speed
- 1/10000 Second
- Longest Shutter Speed
- 1/3 Second
- Network & Communication
- Connectivity Technology
- Wired
- Ethernet Technology
- Fast Ethernet
- Protocols
- TCP/IP
- UDP
- ICMP
- HTTP
- HTTPS
- DHCP
- DNS
- RTSP
- NTP
- UPnP
- SSL/TLS
- FTP
- SFTP
- RTP
- IPv4
- IPv6
- ARP
- Remote Management
- Yes
- Storage
- Storage Type
- Memory Card
- Interfaces/Ports
- Network (RJ-45)
- Yes
- Power Description
- Maximum Power Consumption
- 10.50 W
- Input Voltage
- 12 V DC
- Power Source Type
- DC
- PoE
- Physical Characteristics
- Mount Type
- Ceiling Mount
- Wall Mount
- Pole Mount
- Form Factor
- Bullet
- Durability
- Water Proof
- Weather Proof
- Product Material
- Metal
- Height
- 4"
- Width
- 4.8"
- Length
- 10"
- Weight (Approximate)
- 2.40 lb
- Environmental Conditions
- Minimum Operating Temperature
- -22°F (-30°C)
- Maximum Operating Temperature
- 140°F (60°C)
- Minimum Storage Temperature
- -40°F (-40°C)
- Maximum Storage Temperature
- 140°F (60°C)
- Maximum Operating Humidity (Non-condensing)
- 95%
- Maximum Storage Humidity (Non-condensing)
- 95%
- Miscellaneous
- Features
- Alarm Triggering
- Vehicle Detection
- Human Detection
- Wide Dynamic Range
- 3D Digital Noise Reduction
- Noise Reduction
- White Balance
- Built-in Microphone
- Day/Night
- Mirror
- Indoor/Outdoor
- Outdoor
- Package Contents
- 4MP Outdoor Full-Color 4G Bullet Network Camera
- Quick Start Guide
- Waterproof Cable Attachments
- Mounting Accessories
- Power Adapter
- Ingress Protection Rating
- IP66
- Energy Star
- Yes
- Environmental Compliance
- Restriction of Hazardous Substances (RoHS)
